Equipment:
Smart Liquified Natural Gas Plants
Manufacturer:
SIAD Macchine Impianti, Bergamo (Italy), established in 1927
Range:
SMART LIN-LNG:
Liquefaction frigories from Liquid Nitrogen (LIN)
Nm3/h: up to 1,400
tons/day(TPD): up to 25
Kg/h: up to 1,040
SMART TB-LNG:
Plants with nitrogen closed loop including expansion turbine and booster
Nm3/h: up to 11,200
tons/day(TPD): up to 200
Kg/h: up to 8,333
SMART INT-LNG:
Plants integrated with an ASU and combined production of LNG and LIN
Nm3/h: up to 11,200 +LIN
tons/day(TPD): up to 200 +LIN
Kg/h: up to 8,333 +LIN
Industries: Click here
The technology:
Robust cryogenic technology (SIAD experience)
Highly reliable and efficient machines (compressors and turbines)
Easy plant startup and well suited to frequent start/stop cycles
Lower Capex compared with flammable mixed refrigerant (MR) technology
Lower maintenance costs
Nitrogen easily available on the market or easy production on site
The process:
Simple process and control system
Adaptability to variations in composition of the NG to be liquefied
Optimum efficiency even with high gas network pressure (> 15 bar)
Flexible liquefaction process: flow rate changes easily absorbable
Safety & environmental impact:
Safety in operation: the refrigerant fluid is nitrogen (an inert gas) instead of a mixture of hydrocarbons, which are flammable
No chemical substances used
Absence of liquid hydrocarbon storage systems for refrigerant mixtures
Personnel with specific experience in the management of hydrocarbon mixtures not required
![](http://www.q-boss.com.au/wp-content/uploads/2019/04/smart-lng.png)
